| FRAME |
Alpha Platinum Aluminum, tapered head tube, internal routing, BSA 73, hidden rack and kickstand mounts, UDH, Boost148, 12mm thru axle
BB Standard: BSA, 73mm, Threaded
Hanger Standard: UDH
Tire Clearance: 2.4"
Color: Lavender Haze | Satin Trek Black / Lithium Grey
|
|---|
| FORK |
RockShox Judy Silver, Solo Air spring, TurnKey lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 120mm travel
Travel: 120mm
Spring Type: Air
|
|---|
| Bottom Bracket
|
Shimano BB-MT501 BSA
|
|---|
| Headset
|
Semi-integrated, loose ball bearing, 1-1/8'' top, 1.5'' bottom
|
|---|
| Stem
|
Bontrager Comp Blendr Stem, 31.8x50mm, 7 Degree Rise, Black - S: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length; M, ML: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm length; L: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length; XL: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
|
|---|
| Handlebar
|
Bontrager Comp Lowriser, 31.8x720mm, 5mm Rise, 9D Bend/4D Upsweep, Black - S, M: Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width; S, M: Bontrager alloy, 31.8mm, 5mm rise, 720mm width; ML, L, XL: Bontrager alloy, 31.8mm, 15mm rise, 750mm width
|
|---|
| Saddle
|
Verse Short, steel rails, 145mm width
|
|---|
| Seatpost
|
Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 310mm length - S, M: Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 310mm length; ML, L: Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6mm, 410mm length; XL: Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 31.6mm, 450mm length
Type: Dropper
|
|---|
| Pedals
|
VP-536 nylon platform
|
|---|
| Grips
|
Bontrager Grips XR Trail Comp Black - S, M, ML, L, XL: Bontrager XR Trail Comp, nylon lock-on; S, M, ML, L, XL: Trek Line Comp, nylon lock-on
|
|---|
| Rear Derailleur
|
Shimano XT M8100, long cage
|
|---|
| Crank
|
Shimano Deore Crankset. Item Number: FC-MT512-1, 1x, 12-Speed, 30T, 170mm, HollowTech 2, Without Chainguard (Visit si.shimano.com for compatibility, manuals and exploded views) - S, M: Shimano MT512, 30T ring, 55mm chainline, 170mm length; ML, L, XL: Shimano MT512, 30T ring, 55mm chainline, 175mm length
|
|---|
| Shifters
|
Shimano Deore M6100, 12 speed
|
|---|
| Cassette
|
Shimano Deore M6100, 10-51, 12 speed
|
|---|
| Chain
|
Shimano Deore M6100, 12 speed
|
|---|
| Brakes
|
Shimano MT200 hydraulic disc
Type: Shimano Hydraulic Disc
|
|---|
| Rims
|
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, Presta valve
|
|---|
| Front Hub
|
Shimano TC500 alloy, centerlock, 110x15mm thru axle
|
|---|
| Rear Hub
|
Shimano TC500 alloy, centerlock, 148x12mm thru axle
|
|---|
| Tires
|
Bontrager Sainte-Anne Pro XR TLR 29 x 2.40, 60TPI, Dual Compound, Aramid Bead - S, M, ML, L, XL: Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.20''; S, M, ML, L, XL: Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60tpi, 29x2.40''
|
|---|
| Disc Rotors
|
Shimano Altus Rotor. Item Number: SM-RT10-S, 160mm, Center Lock, For Resin Pad only. (Visit si.shimano.com for compatibility, manuals and exploded views) - S, M, ML, L, XL: Shimano RT10, centerlock, 160mm; L, XL: Shimano RT10, centerlock, 180mm
|
|---|
