| FRAME |
Alpha Platinum Aluminum, tapered head tube, top tube bag mounts, strapless full frame bag mounts, downtube fender mount, lower downtube accessory mount, seat stay rear rack mounts, internal rear derailleur & dropper post routing, 100mm threaded BB, UDH, 197x12mm
BB Standard: BSA, 100mm, Threaded
Hanger Standard: UDH
Tire Clearance: 4.5"
Color: Mercury
|
|---|
| FORK |
Farley carbon, tapered alloy steerer, crown rack mounts, lower leg cage mounts, 150x15mm thru axle
|
|---|
| Bottom Bracket
|
SRAM DUB, 100mm, BSA threaded
|
|---|
| Headset
|
FSA IS-2, 1-1/8'' top, 1.5'' bottom
|
|---|
| Stem
|
Bontrager Comp Blendr Stem, 31.8x50mm, 7 Degree Rise, Black - S: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length; M: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length; L, XL: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 70mm length
|
|---|
| Handlebar
|
Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width
|
|---|
| Saddle
|
Bontrager Verse Elite, austenite rails, 145mm width
|
|---|
| Seatpost
|
TransX 100mm Dropper Post, 31.6mm, internal routing, 361mm Length, 80mm Min Insertion, 2-bolt cradle, TRANZX part number YSP-18PLQ - S: TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length; M: TranzX JD-YSP18, 130mm travel, internal routing, 31.6mm, 425mm length; L, XL: TranzX JD-YSP18, 150mm travel, internal routing, 31.6mm, 470mm length
Type: Dropper
|
|---|
| Pedals
|
VP-536 nylon platform
|
|---|
| Grips
|
Bontrager XR Trail Comp, nylon lock-on
|
|---|
| Rear Derailleur
|
SRAM GX Eagle
|
|---|
| Crank
|
SRAM X1 1000 Eagle, DUB, 30T alloy FAT 5 ring, 170mm length - S, M, L: SRAM X1 1000 Eagle, DUB, 30T alloy FAT 5 ring, 170mm length; XL: SRAM X1 1000 Eagle, DUB, 30T alloy FAT 5 ring, 175mm length
|
|---|
| Shifters
|
SRAM GX Eagle, 12 speed
|
|---|
| Cassette
|
SRAM PG-1230 Eagle, 11-50, 12 speed
|
|---|
| Chain
|
SRAM NX Eagle, 12 speed
|
|---|
| Brakes
|
SRAM Level Bronze 4-piston hydraulic disc
Type: SRAM Level Hydraulic Disc
|
|---|
| Rims
|
SUNRingle Mulefut 80 SL, 32-hole cutout
|
|---|
| Front Hub
|
Bontrager alloy, sealed bearing, 6-bolt, 15x150mm thru axle
|
|---|
| Rear Hub
|
Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano 10 freehub, 197x12mm thru axle
|
|---|
| Tires
|
Bontrager Gnarwhal Team Issue, Tubeless Ready, Inner Strength sidewalls, studdable, aramid bead, 120 tpi, 27.5x4.50''
|
|---|
| Disc Rotors
|
SRAM Disc Brake Rotor, Centerline, 6-Bolt, 160mm, SRAM part number 00.5018.111.001 - S, M, L, XL: SRAM CenterLine, 6-bolt, round edge, 160mm; S, M, L, XL: SRAM CenterLine, 6-bolt, round edge, 180mm
|
|---|
| Accessories
|
Racks :
Trek Farley 2023 Rear Cargo Rack, Paint match Gloss Lava Red - S, M, L, XL: Farley custom rear rack, Lava gloss; S, M, L, XL: Farley custom front rack, Lava gloss
|
|---|
