| FRAME |
800 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle
BB Standard: T47, Threaded
Tire Clearance: 38c
Colors: Matte Deep Smoke | Gecko Phaze | Metallic Red Smoke to Red Carbon Smoke | Era White / Supernova Marble
|
|---|
| FORK |
Domane SLR carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, carbon dropouts, 12x100mm thru axle
|
|---|
| Bottom Bracket
|
SRAM DUB, T47 threaded, internal bearing
|
|---|
| Stem
|
Bontrager RCS Pro, -7 degree, 70mm length - 47: Trek RCS Pro, -7 degree, 70mm length; 50: Trek RCS Pro, -7 degree, 80mm length; 52, 54: Trek RCS Pro, -7 degree, 90mm length; 56, 58: Trek RCS Pro, -7 degree, 100mm length; 60, 62: Trek RCS Pro, -7 degree, 110mm length
|
|---|
| Handlebar
|
Bontrager Aero Pro Handlebar, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 38cm width - 47: Bontrager Aero Pro, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 35cm control width, 38cm width; 50, 52: Bontrager Aero Pro, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 37cm control width, 40cm width; 54, 56, 58: Bontrager Aero Pro, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 39cm control width, 42cm width; 60, 62: Bontrager Aero Pro, OCLV Carbon, 31.8mm, Di2 routing, 80mm reach, 124mm drop, 41cm control width, 44cm width
|
|---|
| Saddle
|
Verse Short Pro, carbon rails, 145mm width
|
|---|
| Seatpost
|
Domane carbon seatpost, KVF2 shaping, 20mm offset, 280mm length - 47, 50, 52, 54, 56: KVF aero carbon seatpost, 20mm offset, 280mm length; 58, 60, 62: KVF aero carbon seatpost, 20mm offset, 320mm length
Type: Rigid
|
|---|
| Rear Derailleur
|
SRAM RED AXS E1, 36T max cog
|
|---|
| Front Derailleur |
SRAM RED AXS E1, braze-on
|
|---|
| Crank
|
SRAM RED AXS E1 Crankset w/ Power Meter, 46/33T, DUB, 165mm Length, SRAM PN: 00.6118.679.013 - 47, 50: SRAM RED AXS E1, power meter, 46/33, DUB, 165mm length; 52, 54, 56: SRAM RED AXS E1, power meter, 46/33, DUB, 170mm length; 58, 60, 62: SRAM RED AXS E1, power meter, 46/33, DUB, 172.5mm length
|
|---|
| Power Meter
|
SRAM RED AXS E1 Crankset w/ Power Meter, 46/33T, DUB, 165mm Length, SRAM PN: 00.6118.679.013 - 47, 50: SRAM RED AXS E1, power meter, 46/33, DUB, 165mm length; 52, 54, 56: SRAM RED AXS E1, power meter, 46/33, DUB, 170mm length; 58, 60, 62: SRAM RED AXS E1, power meter, 46/33, DUB, 172.5mm length
|
|---|
| Shifters
|
SRAM RED AXS E1
|
|---|
| Cassette
|
SRAM RED XG-1290 E1, 10-36, 12 speed
|
|---|
| Chain
|
SRAM RED E1, 12/13 speed
|
|---|
| Brakes
|
SRAM Red AXS E1 hydraulic disc, flat mount
Type: SRAM RED Hydraulic Disc
|
|---|
| Rims
|
Front: Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51mm rim depth, 100x12mm thru axle, Rear: Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51mm rim depth, Shimano 11/12 freehub, 142x12mm thru axle
|
|---|
| Tires
|
Bontrager Kwaremont RSL TLR, tubeless ready, folding bead, Race Dual-Compound, 320 tpi, 700x32mm
|
|---|
| Disc Rotors
|
SRAM Paceline X, rounded, centerlock, 160mm
|
|---|
