| FRAME |
Oltre carbon aero shape, electronic drivetrain only, headset 1.1/4-1.1/4,BB-PressFit 86,5x41mm, integrated seat clamp, for flat mount caliper, internal cable routing for disc brakes, thru axle 12x142mm, sizes 47-50-53-55-57-59cm
BB Standard: BB86/BB92, 86mm, Press Fit
Color:
Blue Italia - Yellow Heritage
Celeste Spectrum - White Alabaster
|
|---|
| FORK |
Full Carbon aero, Disc brakes, integrated head 1.1/4, flat mount caliper, thru axle 12x100mm
|
|---|
| Bottom Bracket
|
Clavicula Pressfit
|
|---|
| Headset
|
Fsa No. 54 - MR137 - ACB 1-1/4diam.46.9x diam.37x7
|
|---|
| Stem
|
Integrated handlebar Integrated Aero bar, material carbon, drop 125mm, reach 80mm, Di2 compatible Ext: 90x400-47/50cm ; 100x400-53cm; 110x420-55/57cm; 120x420-59cm
|
|---|
| Handlebar
|
Included in the stem
|
|---|
| Saddle
|
Fizik Vento Argo 00 Adaptive, Full carbon shell, Adaptive padding technology, Carbon rails, length: 265 mm, width: 140 mm, weight: 153 g
|
|---|
| Seatpost
|
Oltre Full Carbon Aero special dimension seatpost, 20mm offset, length: 280mm-47cm, 300mm-50/55cm, 350mm-57/59cm
Type: Rigid
|
|---|
| Rear Derailleur
|
Shimano Durace Di2 12sp, RD-R9250 Ceramicspeed cage, OSPW Aero Alpha
|
|---|
| Front Derailleur
|
Shimano Durace Di2 12sp,FD-R9250
|
|---|
| Crank
|
THM-Carbones Clavicula SE Powermeter, BCD 110 mm, 5 bolts; Chainrings Carbon-Ti X-CarboRing 52x36T; Crank length: 165 mm (47/53 cm), 170 mm (55/59 cm)
|
|---|
| Power Meter
|
THM-Carbones Clavicula SE Powermeter, BCD 110 mm, 5 bolts; Chainrings Carbon-Ti X-CarboRing 52x36T; Crank length: 165 mm (47/53 cm), 170 mm (55/59 cm)
|
|---|
| Shifters
|
Shimano Durace Di2 hydraulic disc brake for road, ST-R9270, BR-R9270, for 160mm rotor
|
|---|
| Cassette
|
Shimano Durace 12sp, CS-R9200, 11-12-13-14-15-16-17-19-21-24-27-30T
|
|---|
| Chain
|
Shimano Durace 12sp, CN-M9100
|
|---|
| Brakes
|
Shimano BR-R9270 Hydraulic disc brake, included in the shifter
Type: Shimano Dura-Ace Hydraulic Disc
|
|---|
| Rims
|
Scope Artech 6.A, 65 mm profile, 700x25C, HG body, Aeroscales rim structure, 3D printed hubs, 36T diamond Ratchet SL system, Carbonlite Aerospoke, weight per set: 1319 g
|
|---|
| Tires
|
Pirelli P ZERO™ Race RS TLR, 30-622, SmartEvo compound, Speedcore TLR technology, 120 tpi
|
|---|
| Disc Rotors
|
Carbon-Ti, X-Rotor Aero Center Lock, 160 mm front and rear
|
|---|
