| FRAME |
OCLV Mountain Carbon, high main pivot, idler pulley, internal storage, angle-adjust headset, adjustable leverage rate, integrated frame protection, internal routing, alloy rocker link, ISCG 05, Active Braking Pivot, UDH, 148x12mm thru axle, 170mm travel
BB Standard: BSA, 73mm, Threaded
Hanger Standard: UDH
Tire Clearance: 2.5"
Color: Daintree
|
|---|
| FORK |
RockShox ZEB Select+, DebonAir spring, Charger 3 RC2 damper, tapered steerer, 44mm offset, Boost110, Maxle Stealth, 170mm travel
Travel: 170mm
Spring Type: Air
|
|---|
| Shock
|
RockShox Vivid Select+, 230mm x 65mm
Travel: 170mm
|
|---|
| Bottom Bracket
|
SRAM DUB MTB Wide, 73mm, BSA threaded
|
|---|
| Headset
|
Integrated cartridge bearing, 1-1/8'' top, 1.5'' bottom, angle adjust cup compatible
|
|---|
| Stem
|
Bontrager Line Pro, 35mm, Blendr compatible, 0 degree, 35mm length
|
|---|
| Handlebar
|
Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 820mm width
|
|---|
| Saddle
|
Bontrager Arvada, austenite rails, 138mm width
|
|---|
| Seatpost
|
Bontrager Dropper Seatpost Line Elite Oversized 34.9mm Diameter 100mm Travel - S : Bontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 345mm length; M, ML: Bontrager Line Elite Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 485mm length; L, XL: Bontrager Line Elite Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 550mm length
Type: Dropper
|
|---|
| Grips
|
Bontrager XR Trail Pro, alloy lock-on
|
|---|
| Rear Derailleur
|
SRAM GX Eagle AXS, T-Type
|
|---|
| Crank
|
SRAM GX Eagle, DUB MTB Wide, T-Type, 30T, 55mm chainline, 165mm length
|
|---|
| Shifters
|
SRAM AXS POD
|
|---|
| Cassette
|
SRAM Eagle XS-1275, T-Type, 10-52, 12 speed
|
|---|
| Chain
|
SRAM GX Eagle, T-Type, 12 speed
|
|---|
| Brakes
|
SRAM CODE Bronze 4-piston hydraulic disc
Type: SRAM Hydraulic Disc
|
|---|
| Rims
|
Bontrager Line Elite 30, Tubeless Ready
|
|---|
| Front Hub
|
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle
|
|---|
| Tires
|
Bontrager SE5 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 27.5x2.50'' - S , M, ML, L, XL: Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 27.5x2.50''; M, ML, L, XL: Bontrager SE6 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50''
|
|---|
| Disc Rotors
|
SRAM CenterLine, 6-bolt, round edge, 200mm
|
|---|
| Accessories
|
Fenders: Trek 27.5" custom fender
|
|---|
