| FRAME |
OCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9mm seat tube, upper chain guide mount, 55mm chainline, Mino Link, ABP, Boost148, UDH, 140mm travel
Hanger Standard: UDH
Tire Clearance: 2.5"
Color: Deep Smoke
|
|---|
| FORK |
RockShox Lyrik Ultimate, AirWiz, DebonAir spring, Charger 3 RC2 damper, 44mm offset, Boost110, Maxle Stealth, 150mm travel
Travel: 150mm
Spring Type: Air
|
|---|
| Shock
|
RockShox Super Deluxe Ultimate AirWiz, RCT2 damper, 205mm x 60mm
Travel: 140mm
|
|---|
| Headset
|
Integrated cartridge bearing, 1-1/8'' top, 1.5'' bottom
|
|---|
| Saddle
|
Bontrager Arvada, austenite rails, 138mm width
|
|---|
| Seatpost
|
Size: S, RockShox Reverb AXS, 100mm travel, wireless, 34.9mm, 340mm length; Size: M, RockShox Reverb AXS, 150mm travel, wireless, 34.9mm, 440mm length; Size: L, XL, RockShox Reverb AXS, 170mm travel, wireless, 34.9mm, 480mm length
Type: Dropper
|
|---|
| Grips
|
Bontrager XR Trail Elite, nylon lock-on
|
|---|
| Rear Derailleur
|
SRAM X0 Eagle AXS, T-Type
|
|---|
| Crank
|
SRAM X0, 165mm length
|
|---|
| Shifters
|
SRAM AXS POD Ultimate, paired with dropper
|
|---|
| Cassette
|
SRAM Eagle XS-1295, T-Type, 10-52, 12 speed
|
|---|
| Chain
|
SRAM X0 Eagle, T-Type, 12 speed
|
|---|
| Brakes
|
SRAM Code Silver 4-piston hydraulic disc
Type: SRAM Hydraulic Disc
|
|---|
| Rims
|
Front: Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29'', Rear: Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12mm thru axle, 29''
|
|---|
| Tires
|
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50''
|
|---|
| Disc Rotors
|
SRAM 6-bolt, 200mm
|
|---|
|
|
Electric Components
|
|---|
| Motor
|
TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
|
|---|
| Battery
|
Size: S, M, L, XL, TQ 360Wh
|
|---|
| Display
|
TQ LED display with Bluetooth & ANT+ connectivity
|
|---|
| Charger
|
TQ 4A charger
|
|---|
