| FRAME |
Carbon technology frame, 125mm F.O.L.D. GEN3 kinematics, 148x12 thru axle, internal cable routing, Post Mount 180 mm
|
|---|
| FORK |
SR Suntour Raidon 34, 110x15 mm, 44 mm rake
Travel: 130mm
Spring Type: Air
|
|---|
| Shock |
Rock Shox Deluxe Select+, 210/50 mm, hardware: 25.0 x 8.0 mm, no Bushing
Travel: 125mm
Spring Type: Air
|
|---|
| Bottom Bracket
|
Integrated in Drive Unit
|
|---|
| Headset |
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated, 1.5/1.5" angle headset
|
|---|
| Stem |
FOCUS C.I.S. 50 mm, 0°, 35 mm, aluminium
|
|---|
| Handlebar
|
Aluminium, 800 mm, rise: 30 mm, backsweep: 9°
|
|---|
| Saddle |
fi'zi:k Taiga
|
|---|
| Seatpost
|
Post Moderne dropper post PM-MT171, 31.6 mm
Type: Dropper
|
|---|
| Grips
|
VP VPG-122A
|
|---|
| Rear Derailleur
|
Shimano Deore M6100, 12-speed
|
|---|
| Crank |
Samox EC38 ISIS
|
|---|
| Shifters |
Shimano Deore M6100, 12-speed
|
|---|
| Cassette |
Shimano Deore CS-M6100, 12-speed
|
|---|
| Chain |
Shimano Deore CN-M6100, 12-speed
|
|---|
| Brakes |
Magura MT Trail, front: 4-piston / rear: 2-piston
Type: Hydraulic Disc
|
|---|
| Rims |
RaceFace ARC27, 622-27, 32H
|
|---|
| Spokes |
Niro, black
|
|---|
| Front Hub |
Shimano MT410, 15x110 mm
|
|---|
| Rear Hub |
Shimano MT410, 12x148 mm
|
|---|
| Tires |
Front: Maxxis Dissector, 2.4 Exo, 61-622, Rear: Maxxis Rekon, 61-622
|
|---|
|
Electric Components
|
|---|
| Motor |
Fazua Ride 60, 60 Nm, 430 W max.
|
|---|
| Battery |
Fazua 36V (430Wh)
|
|---|
